Brand Name : ECOOGRAPHIX
Model Number : Ecoo-VD240
Certification : CE
Place of Origin : CHINA
MOQ : 1SET
Price : Negotiable
Payment Terms : L/C, T/T
Supply Ability : 300SET
Delivery Time : about 20days
Packaging Details : standard export packing
Max Die Cutting Width : 210mm
speed : 8m/minute(7cm *15cm) SS
Technology : Tungsten steel rotary blade
Substrates : PP,PET ,Paper,Foil
Warranty : One Year
Laminate Width : 240mm
Max Label Length : 300mm
240mm Roll Label Desktop Small Quantity Sample Digital Die Cutter
Introduction:
As society progresses and consumer demand for product diversification grows, there's an increasing need for labeling and customization across various industries. Label printing companies and enterprises alike seek digital label printers to streamline printing processes and reduce costs associated with time and labor. With a diminishing workforce skilled in traditional printing methods, the simplicity of operation and maintenance offered by digital products has made significant inroads into the label printing market. Gradually, digital printers are poised to replace traditional printing presses. Ecoo Digital Label Printer caters to diverse customer needs by offering competitive printing costs and lower product prices.
Machine Highlights:
- Achieves high speed and precision with full-servo motor technology.
- Integrates lamination, die-cutting, waste removal, slitting, and rewinding functions into a single machine for seamless operation.
- Dual head design automatically adjusts and distributes the cutter for enhanced efficiency.
- Utilizes Sick track sensor technology to track single or double eye marks accurately.
- Supports QR code or digital automatic file switching, enabling automatic access to cut files.
- Employs intelligent cutting with trajectory optimization for optimal performance.
Parameters and specifications | |
Maximum winding and unwinding | 290mm |
Support material width | 80-240mm |
Maximum label width | 230mm |
Minimum label length | 10mm |
Maximum label length | 300mm (maximum label length for plate cutting 2000mm) |
Die cutting speed | 9m/min |
Number of die-cutting machine heads | 2 |
Data interface | USB2.0 |
Die-cutting technology | Hard alloy rotary cutting tool |
Mould-cutting precision | 0.1mm |
Die cutting positioning | Black Label Single/Double Dot/CCD |
Size | 910*630*740 |
Weight | 120kg |
Power supply | 110-127VAC 50-60HZ,1000W 220-240VAC 50-60HZ,1000W |
Warranty service | One year (excluding vulnerable parts) |
![]() |
High-Speed and Precision Label Printing Machine with Full-Servo Motor Technology Images |
